手板报价是一个具有丰富技术基础的工作，由于手板是属于定制性的产品，很难有参考性，下面我们就简单的聊聊，有哪些因素会影响济南手板的。

Handboard quotation is a job with a rich technical foundation. As handboards are customized products, it is difficult to have reference prices. Below, we will briefly discuss which factors will affect the price of Jinan handboards.

1.手板的成型方式选择：

1. Selection of molding method for the hand board:

对于现在而言，我们一般的手板成型方式分为cnc加工、3D打印和小批量复模，而我们在考虑材料使用什么材料的同时都会去选择相对应的成型方式。一般材料要求比较高的时候我们都是选择使用cnc加工型材，成本虽然高，但是材料的稳定性可以得到保证。而如果是数量在十多件材料要求只是近似于ABS的情况下我们都会选择使用小批量复模的方式，做一两个原型加上简单硅胶模具，在时间成本方面都比cnc加工大大的节约了很多。3D打印的成本相对较低，但材料强度和耐温性却远远不如CNC和复模手板。

For now, our general molding methods for hand boards are divided into CNC machining, 3D printing, and small batch copying, and we will choose the corresponding molding method while considering which material to use. When the material requirements are relatively high, we usually choose to use CNC to process profiles. Although the cost is high, the stability of the material can be guaranteed. If the quantity is over ten pieces and the material requirements are only similar to ABS, we will choose to use a small batch of re molding, making one or two prototypes and adding a simple silicone mold, which greatly saves a lot of time and cost compared to CNC processing. The cost of 3D printing is relatively low, but the material strength and temperature resistance are far inferior to CNC and replica hand boards.

2.手板使用的材料：

2. Materials used for the hand board:

有时候我们选择不同的材料报价的时候会发现可能相差好几倍，那到底是什么原因呢？，不同材料的是不同的，像PEEK、铁氟龙等特殊材料就会比平常ABS、PC、PMMA等材料贵几倍几十倍；其次，不同材料的加工时间是不一样的，像铝合金不锈钢POM等比较硬性的材料就比平常ABS、PC等塑胶等更难加工，铣刀跑的速度就会比较慢更耗费时间。

Sometimes when we choose different material quotations, we may find that the prices may vary several times. So what is the reason? Firstly, the prices of different materials vary, and special materials such as PEEK and Teflon are several times and dozens of times more expensive than ordinary materials such as ABS, PC, and PMMA; Secondly, the processing time for different materials is different. Harder materials such as aluminum alloy, stainless steel, and POM are more difficult to process than ordinary plastics such as ABS and PC, resulting in slower and more time-consuming milling cutters.

3.表面工艺的差别：

3. Differences in surface technology:

白板件或者内部件的话我们一般都是加工下来去下毛刺或者打磨开粗，但是需要喷漆、电镀、透明等工艺的时候就需要我们打磨师傅一个很精细的打磨，人工成本就增加了很多，自然而然方面也会相对更多。

For whiteboard or internal components, we usually process them to remove burrs or grind them rough. However, when painting, electroplating, transparency, and other processes are required, our polishing master needs to perform a very precise polishing, which increases labor costs significantly and naturally leads to a relatively higher price.

4.手板制作存在的风险率：

4. Risk rate of hand board production:

很多朋友都知道，镁合金加工都是比较昂贵的，那是为什么呢？因为镁合金材料活动性非常高，导致燃点很低，加工的时候稍不注意或者方式不当就很容易导致着火，造成不可估量的损失。还有一些其他活动性比较高的材料以及有些结构壁厚比较薄的都是会产生报废率，所以手板报价评估人员都会按照风险程度的不同而给出不一样的。

Many friends know that magnesium alloy processing is relatively expensive, so why? Due to the high activity of magnesium alloy materials, their ignition point is very low. Slight carelessness or improper processing can easily lead to ignition, resulting in incalculable losses. There are also other materials with high activity, as well as some structures with thin wall thicknesses, which can result in scrap rates. Therefore, the quotation evaluators of the hand board will provide different prices based on the degree of risk.

5.加急件和订单饱和度：很

5. Urgent parts and order saturation: very high

多朋友有时候会遇到手板很急着做出来的情况，可能正常制作5天周期两三天就需要拿到手板。这种时候每个手板厂商都会先查看已有订单的饱和度来评估，优先安排势必会影响其它订单的进度，也会导致人员的加班加点。所以手板报价人员会根据订单饱和度，在保证其他订单能顺利完成的情况下做出浮动。

Many friends may sometimes encounter situations where they are in a hurry to create a prototype, and they may need to obtain the prototype within a normal 5-day production cycle of 2-3 days. At this time, each tablet manufacturer will first assess the saturation of existing orders, and prioritizing arrangements will inevitably affect the progress of other orders and also lead to overtime work for personnel. So the manual quotation personnel will make price fluctuations based on order saturation while ensuring the smooth completion of other orders.

大多数手板厂是根据报价工程师自己对手板制作的各项工艺进行难易度评估，存在着较大的主观思维，而名欣模型却有所不同，我们是把图档整理好之后，把相关的负责人召集到一起探讨工艺、工时，详细分析各项成本、风险、交期，这样更能确保报价的准确性。您有需求就来咨询联系我们http://m.axcwv.cn！

Most handicraft factories evaluate the difficulty of various handicraft production processes based on the quotation engineers themselves, and there is a significant subjective thinking. However, the Mingxin model is different. After organizing the drawings and files, we gather the relevant responsible persons to discuss the process, working hours, and conduct a detailed analysis of various costs, risks, and delivery times, which can better ensure the accuracy of the quotation. If you have any needs, please contact us for consultation http://m.axcwv.cn ！
